Technical Specifications for 1771-OM
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Backplane Current
|
225 Miliamperes
|
|
Part Number/Catalog No.
|
1771-OM
|
Input Voltage
|
220 Volts AC
|
|
Module Type
|
Digital Output Module
|
Inrush Current
|
20 amps
|
|
Manufacture Year
|
2022
|
Input Power
|
85 Watts
|
|
Product Package
|
Original Package
|
UPC
|
10612598494855
|
About 1771-OM
|
The 1771-OM is an Digital AC Output Module. The 1771-OM PLC 5 Digital AC Output Module by is an output module with 8 fused AC Triac outputs located on any slot of the 1771 I/O chassis. It has an operational output voltage range of 184-250V AC at 47 - 63Hz with an output current of 2A which must not exceed 6A for the entire module and a current surge of 20A for 100ms on each output repeatable every 10 seconds.
At 220V AC and 60Hz, the minimum current required by the module to remain ON is 60mA, and at any value below this, the Triac output, it will not operate. The 1771-OM has an ON-state maximum voltage loss of 1.6V at 2A with 2mA per output leakage current at 220V AC in the OFF state and the module draws 225mA at 5V DC (+5%) backplane current from the I/O chassis.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
