Part Number/Catalog No. |
1771-OYC |
|
Module Type |
Contact Output Module |
|
Max Voltage Per Output |
30 VA at 138 VAC or 20 VA at 125 VDC |
|
Model Status |
Earlier Model |
|
AC Operating Voltage |
0-250 Volts |
|
DC Operating Voltage |
0-175 Volts |
|
Backplane Current |
550 Miliamperes |
|
Max Continuous Current Per Module |
N/A |
|
Wiring Arm |
1771-WH |
|
Note |
Contains Mercury |
|
Typical AC Signal Delay (Off) |
45 (+/- 15) ms |
|
Typical DC Signal Delay (Off) |
50 ms |
The 1771-OYC is a contact output module designed for industrial automation systems. It supports a maximum voltage of 30 VA at 138V AC or 20 VA at 125V DC. The AC operating voltage range is from 0-250V AC, while the DC operating voltage spans from 0-175V DC. The module requires a backplane current of 550 mA and can handle a maximum continuous current of 2 A at 100V AC, with a maximum power rating of 200 VA.
For signal processing, the typical AC signal delay is 45 +/-15 ms, and the typical DC signal delay is 50 ms when the module is in the off state. The wiring arm used for this module is the 1771-WN. The module weighs approximately 3 lbs and contains mercury, so it should be handled with care to avoid breaking the glass capsule containing the mercury, especially in environments with excessive vibrations.
