1785-ENET  PLC-5 Ethernet Interface Module



Allen Bradley  1785-ENET !!!  --- sales3@amikon.cn


Contact:Jessica

Email:sales3@amikon.cn

Skype:jessica01235483

Wechat:hu18030235311

Mobile:86-18030235311(WhatsApp)




The 1785-ENET PLC-5 EtherNet Interface Module by Allen-Bradley is an EtherNet/IP enabled interface module located on a single I/O slot in the 1771 I/O chassis. When attached to the Programmable Logic Controller (PLC-5), it enables EtherNet connectivity on the controller. This module has a backplane rating of 1.0 Amps at 5 Volts DC and it dissipates 5 Watts of power. When used with an enhanced PLC-5 controller, the 1785-ENET enables EtherNet connectivity without disabling the DH+/RIO ports, and it conveniently provides Ethernet connectivity with a ControlNet PLC-5 controller. It can also run dual Ethernet links with the Ethernet PLC-5 controller.



The 1785-ENET PLC-5 EtherNet/IP Interface Module is in direct connection to channel 3 of a PLC-5 processor.

1785ENET operations include processing messages. Communication port protocol is EtherNet/IP.




Attribute  Value
Backplane Current  1.0 A @ 5V dc
Power Dissipation  5 W
Heat Dissipation  17.06 BTU/hr
IEC Temp Code  T5
North American Temp Code  T5
Isolation Voltage  50V, Basic Insulation Type
Tested at 500V ac for 60 s, Communications to system
Wire Type  Ethernet: 802.3 compliant shielded or unshielded twisted pair
Wiring Category 2 - on communications ports
Communication  Ethernet (TCP/IP protocol 8-pin RJ45 port)
Weight, Approx.  0.77 kg (1.7 lb)
Dimensions (HxWxD), Approx.  273.05 x 31.75 x 146.05 mm (10.75 x 1.25 x 5.75 in.)




Allen Bradley  1785-ENET


1785-ENET | Allen Bradley |  Ethernet Interface Module




Email:sales3@amikon.cn


  Part Number:
  1785-ENET
  Module Type:
  Communication Module
  Description:
  PLC-5 EtherNet/IP Interface Module
  Communication Port Protocol:
  EtherNet/IP
  Operation:
  Process Messages
  Communication w/ PLC
  Processor:
  Direct Connection to Channel 3 of PLC-5
  Processor
  Dimensions:
  4.5 x 12.4 x 6.3 in (115 x 317 x 160 mm)
