The 1785-L40C PLC-5/40C is an Allen-Bradley Controller with ControlNet Network Capability a 48-KB Word SRAM Processor and ControlNet capability installed on the I/O slot of the 1771 I/O Chassis, and it is used for controlling the outputs and inputs of field devices. The processor has 48KB of maximum user memory words, with a maximum I/O capacity of 2048 (with 2048 in and 2048 out complementary), and a maximum program scan time of 0.5ms per K-word measured in bit logic and the scan time is 2ms per K-word (typical).
The controller draws 3.3A of backplane current at 5V DC, and its maximum heat dissipation is 59 BTU/hour when it is operational. The controller supports the 1785-CHBM ControlNet Hot Backup Cartridge, for use in a hot backup of the system, and it supports the 1771, 1794, 1746, and the 1791 8-point, 16-point, and 32-point modules, and the intelligent I/O modules.
The controller has a base-configured RJ45 Connector ControlNet Network Access Port, with an I/O transmission rate of 5mb per second, and with a user selectable network update time of 2-100ms, and a Co-Processor port.
|
Part Number:
|
|
1785-L40C
|
|
|
|
|
|
Max Analog I/O:
|
|
2048
|
|
|
|
|
|
I/O Scan Time Per Rack:
|
|
10 ms at 57.6 kbits/s, 7 ms at 115.2 kbits/s, 3 ms at
|
|
|
|
230.4 mbits/s
|
|
|
|
|
|
Max I/O Chassis Total:
|
|
61
|
|
|
|
|
|
Max I/O Chassis Extended
|
|
0
|
|
Local:
|
|
|
|
|
|
|
|
Max I/O Chassis Universal
|
|
32 Max. Per I/O Link
|
|
Remote:
|
|
|
|
|
|
|
|
RS-232-C/422-A/423- A
|
|
1
|
|
Ports:
|
|
|
|
|
|
|
|
Control Coprocessor
|
|
YES
|
|
Expansion Port:
|
|
|
Allen Bradley 1785-L40C
1785-L40C | Allen Bradley | PLC-5/40C for ControlNet Phase 1.25
Email:sales3@amikon.cn
Part Number:
|
1785-L40C
|
|
Module Type:
|
ControlNet Processor Module
|
|
Processor:
|
PLC-5/40
|
|
Max User Memory Words:
|
48 Kilowords
|
|
Max Total I/O:
|
2048 (any mix) or 2048 in +
2048 out (complementary)
|
