The 1785-L40C15 PLC-5/40C is an Allen-Bradley Controller with the ControlNet Network, a 4,000-word SRAM controller and a ControlNet network port located on the left-most slot of the 1771 I/O Chassis which draws a 3.3A backplane current, and it is used in an industrial automated process for controlling the outputs/inputs of connected field devices. It has 2048 (any mix) or 2048 in + 2048 out (complimentary) maximum I/O capacity, with a maximum I/O Rack capacity of 15 I/O, and the maximum number of remote I/O devices that can be connected at a time is 60 I/O.
It has 2ms per K word (Typical), and 0.5ms per K word in bit logic program scan time, respectively, and it is designed with a single Co-Processor port. It draws a backplane current of 3.3A from the I/O chassis, at 5V DC, and it will dissipate 59 BTU/hour when operational, and it is keyed in placed through connection to pins 40 and 42, and 54 and 56. The 1785-L40C15 has 3 Hardware Addressing modes, and it supports a ControlNet Hot Backup Cartridge, for use in System Hot-Backup. The controller is also compatible, with the Allen-Bradley 1771, 1794, 1746, and the 1791 8-points, 16-points, 32-points, and intelligent I/O modules and the processor’s SRAM memory is backed up with the 1785-RC Relay Cartridge Battery.
|
Part Number:
|
|
1785-L40C15
|
|
|
|
|
|
Max Analog I/O:
|
|
Forcible 2048 and Nonforcible 48000
|
|
|
|
|
|
I/O Scan Time Per Rack:
|
|
ControlNet I/O 0.5 ms (average); Universal Remote I/O 10 ms
|
|
|
|
at 57.6 kbits/s, 7 ms at 115.2 kbits/s, 3 ms at 230.4 mbits/s
|
|
|
|
|
|
Max I/O Chassis Total:
|
|
125
|
|
|
|
|
|
Max I/O Chassis Extended Local:
|
|
0
|
|
|
|
|
|
Max I/O Chassis Universal Remote:
|
|
60
|
|
|
|
|
|
RS-232-C/422-A/423- A Ports:
|
|
1
|
|
|
|
|
|
Control Coprocessor Expansion Port:
|
|
Yes
|
Allen Bradley 1785-l40C15
1785-l40C15 - Allen Bradley | LControlNet PLC-5 Processor
Email:sales3@amikon.cn
Part Number:
|
1785-L40C15
|
|
Module Type:
|
ControlNet PLC-5 Processor
|
|
Processor:
|
PLC-5/40C
|
Max User Memory Words:
|
48 Kilowords
|
|
Battery-Backed Static RAM:
|
Yes
|
