The 1785-L80C PLC-5/80C ControlNet Programmable Controller by Allen-Bradley is a 100K word programmable controller installed on the 1771 I/O chassis which directs the processes of field devices and has a maximum I/O capacity of 3072. The module requires a backplane current of 3.3A at 5V DC and it has a maximum heat dissipation of 59 BTU/hour when operational.
The controller is designed to function without de-rating at a temperature range between 0 and 60 0C (32 and 140 0F) at a relative humidity range of 5-95% without condensation and it is IEC-tested and rated to withstand 2G of operational vibration at 10-500Hz and a 30G operational shock. The 1785-L80C controller supports the use of the ControlNet hot backup cartridge (1785-CHBM), a battery module (1770-XYC), and a battery-backed memory module (either 1785-ME32, 1785-ME64, or 1785-M100).
The 1785-L80C is designed to be compatible with the 1771 intelligent, 8, 16, and 32-point I/O modules, and address I/O modules through the 2-slot, 1-slot, and ½-slot addressing modes.
The 1785-L80C has an internal circuit clock/calendar with ±5 min per month accuracy variation at 60 0C, with a timing accuracy of 1 program scan, and has a program scan time of 0.5ms per K word (in bit logic), and 2ms per K word. The controller has an RJ-45 type ControlNet Network Access Port (NAP) with a transfer speed of 5 megabits per second, and a 2-100ms user selectable update time on the network.
|
Part Number:
|
|
1785-L80C
|
|
|
|
|
|
Max Analog I/O:
|
|
3072
|
|
|
|
|
|
I/O Scan Time Per Rack:
|
|
10 ms at 57.6 kbits/s, 7 ms at 115.2 kbits/s, 3 ms at
|
|
|
|
230.4 mbits/s
|
|
|
|
|
|
Max I/O Chassis Total:
|
|
93
|
|
|
|
|
|
Max I/O Chassis Extended
|
|
0
|
|
Local:
|
|
|
|
|
|
|
|
Max I/O Chassis Universal
|
|
32 Max. Per I/O Link
|
|
Remote:
|
|
|
|
|
|
|
|
RS-232-C/422-A/423- A
|
|
1
|
|
Ports:
|
|
|
|
|
|
|
|
Control Coprocessor
|
|
Yes
|
|
Expansion Port:
|
|
|
Allen Bradley 1785-L80C
1785-L80C | Allen Bradley CPU Module PLC-5/80C
Email:sales3@amikon.cn
Part Number:
|
1785-L80C
|
|
Processor:
|
PLC-5/80
|
|
Module Type:
|
ControlNet Processor Module
|
|
Max User Memory Words:
|
100 Kilowords
|
|
Max Total I/O:
|
3072 (any mix) or 3072 in +
3072 out (complementary)
|
