Technical Specifications for 1791-16BC
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Voltage
|
24V dc
|
|
Part Number/Catalog No.
|
1791-16BC
|
External Power
|
19.2-30V dc
|
|
Module Type
|
Block I/O
|
Outputs per Block
|
16
|
|
Manufacture Year
|
2021
|
Output Voltage
|
10-30VDC
|
|
Product Package
|
Original Package
|
UPC
|
10612598124753
|
About 1791-16BC
|
1791-16BC supports horizontal and vertical mounting options each of which has its own output current rating. At 60 degrees Celsius, vertical mounting has a current rating of 500 mA while horizontal mounting has a 250 mA current rating. Low temperatures will increase the current rating. The current rating of vertical mounting will increase to 1 Amp at 30 degrees Celsius while horizontal mounting at 30 degrees Celsius will increase the current to 500 milliamps.
The maximum surge current for the1791-16BC is 3 Amps for 50 milliseconds.The 1791-16BC is a Discrete I/O block that is manufactured by . This module features embedded channels composed of Sixteen (16) 10-30VDC input channels and Sixteen (16) 10-30VDC output channels. This module is a compact device that is capable of functioning as a single Remote I/O chassis. It has embedded power supply, communication interface, input and output channels.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
