Technical Specifications for 1791-24B8
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Backplane Current
|
8 Amperes
|
|
Part Number/Catalog No.
|
1791-24B8
|
Input Voltage
|
100 Volts AC
|
|
Module Type
|
Block I/O Module
|
Input Voltage
|
85-110 Volts AC
|
|
Manufacture Year
|
2021
|
Voltage Rating
|
24 VDC
|
|
Product Package
|
Original Package
|
UPC
|
1066246150601
|
About 1791-24B8
|
The 1791-24B8 has an output rating of 500 milliamps/1Amps at 30 to 60 degrees Celsius with a vertical mounting and 250 to 500 milliamps at 30 to 60 degrees Celsius with a horizontal mounting. It has a current that surges at 3 Amps for 50 seconds that keeps recurring after 2 seconds.
The 1791-24B8 has an output OFF-state current of 1 milliamps at a drop voltage of 1 Volts and 0.5 milliamps of current leakage. It has an external power supply with internal protection which supplies voltage in the range between 19.2 and 30 Volts DC at a current of 300 milliamps.
The 1791-24B8 has a maximum thermal dissipation of 58.1 BTU/hour and a maximum power dissipation of 17.1 Watts. It has an operational temperature range between 0 and 60 degrees Celsius (32 and 140 degrees Fahrenheit) at a relative humidity of 5 to 95% non-condensing. The 1791-24B8 measures 176.5 millimeters x 68.8 millimeters x 98 millimeters (6.95 inches x 2.7 inches x 3.85 inches) and it weighs 1.02 kilograms (2.25 pounds).
|
