Technical Specifications for 1794-IB16
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Memory
|
240 KB
|
|
Part Number/Catalog No.
|
1794-IB16
|
Input Power
|
32V DC
|
|
Module Type
|
Digital Input Module
|
Inputs
|
16 Current Sinking
|
|
Manufacture Year
|
2022
|
FlexBus Current
|
60 mA
|
|
Product Package
|
Original Package
|
UPC
|
10612598137784
|
About 1794-IB16
|
The 1794-IB16 module has 16 current sinking inputs with 24V DC nominal On-State voltage, 10-31.2V DC On-State voltage range, and 1.5mA minimum Off-State current. It has a maximum power dissipation of 6.1W at 31.2V DC.The 1794-IB16 has a current draw of 30 mA @ 5V DC. The individual input channels are rated10 to 31.2 VDC with nominal input voltage of 24VDC and supports sink wiring configuration.
The 1794-IB16 is a Sixteen (16) channel 24VDC Discrete input module. This module is part of the 1794 Flex IO product family which is primarily used to implement distributed IO solution. With distributed I/O architecture, I/O modules may be installed near the source of the signal or the driven load. This significantly reduces cable runs thus, reduces overall installation costs. It also simplifies maintenance and contributes to overall increase in the control system uptime.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
