1794-IE8 | Allen Bradley | Analog Module

1794-IE8  Flex I/O High-Density Analog Module has 8 Single-ended Inputs



Allen Bradley   1794-IE8  !!!  ---mail to: sales3@amikon.cn



  Email:     sales3@amikon.cn

                                                                     Contact:  Jessica                   |   Skype:     jessica01235483

                                                                     Wechat:   hu18030235311    Mobile:   86-18030235311(WhatsApp)







The Allen-Bradley 1794-IE8 is a FLEX selectable analog input module. This 24 Volts DC module has 8 single-ended non-isolated inputs and 3 key switch positions. It has a 12-bits unipolarresolution with 11 bits + sign bipolar input resolution. No calibration beyond the factory setting is required for this module. It measures 3.7 x 2.1 x 31.8 inches and can be mounted on a DIN rail or panel mount. The 1794-IE8 module can be installed on a 1794-TB2, 1794-TB3S, 1794-TB3ST, 1794-TB3T, or a 1794-TB3 terminal base unit. It also comes with a power and status indicator and has an open-style enclosure.


This module has a voltage specification of 24 Volts DC nominal, 10.5 to 31.2 Volts DC including the 5% AC ripple, a current specification of 60 mA, a voltage certification of 24 Volts DC, and a current certification of 0 to 10 Volts that is user-configurable.





Allen Bradley    1794-IE8

1794-IE8 | Allen Bradley | Analog Module




         sales3@amikon.cn




It has an absolute accuracy of 0.20% full scale at 25 degrees Celsius and accuracy drift with a temperature of 0.00428% full scale per degree Celsius for the voltage terminal and 0.00407% full scale per degree Celsius for the current terminal.
