The 1794-IP4 is a Pulse Counter Module designed for high-speed calculation and scaling in industrial applications such as speed measurement, quantity counting, and flow monitoring. The module requires an input signal with a 6V amplitude from all connected input devices. For the input to register as "On," a minimum voltage of 6V is required, while the "Off" condition occurs when the voltage is below 3V. It is crucial that the input signals transition smoothly between 3V and 6V, as improper transitions may affect the module's operation.
This module is commonly used in flow and turbine metering applications across industries such as automotive, power management, food and beverage, as well as oil and gas. The 1794-IP4 features 4 pulse counter inputs, divided into two groups of two inputs each. It supports a maximum counting frequency of 100 kHz. The module operates with a nominal external DC supply current of 150mA at 12V DC and 75mA at 24V DC.
|
Feature
|
Details
|
|
Part Number
|
1794-IP4
|
|
Product Description
|
Flex I/O Pulse Counter Module
|
|
Number of Inputs
|
Four (4)
|
|
Number of Input Groups
|
Two (2)
|
|
ON State Voltage (min)
|
6VDC
|
|
ON State Voltage (max)
|
26.4VDC
|
|
ON State Voltage (nom)
|
24VDC
|
|
Enclosure
|
Open-type
|
|
Mounting
|
DIN Rail
|
|
Wire Size
|
Determined by installed terminal base
|
|
Operating Temperature
|
0 to 55°C (32 to 131°F)
|
|
Storage Temperature
|
-40 to 85°C (-40 to 185°F)
|
|
Product Type
|
Flex I/O 4 Channel Pulse Counter Module
|
|
Inputs
|
2 per Interface
|
|
Pulse Counter Interfaces
|
4
|
|
Input Current
|
3mA @ 6V DC
|
|
Input ON Range
|
6-26.4V DC
|
|
Input OFF Range
|
-26.4-3V DC max.
|
|
Enclosure Type Rating
|
None (open-style)
|
|
Flexbus Current
|
5mA @ 5V DC
|
