1794-OE8H | Allen Bradley | I/O Analog Output Module

1794-OE8H   Flex 8 Point Analog Output Module






Allen Bradley  1794-OE8H !!!  --- sales3@amikon.cn


Contact:Jessica

Email:sales3@amikon.cn

Skype:jessica01235483

Wechat:hu18030235311

Mobile:86-18030235311(WhatsApp)




The following features are unique to the 1794-OE8H module:



 There are six values per channel that the I/O module uses to calculate the corresponding calibration values (offset and gain).

   – Min Scale DAC at 1500dec about 1 mA

   – Max Scale DAC at 6700dec about 20 mA

   – Current-read-back Min Scale at 1500dec about 1 mA

   – Current-read-back Max Scale at 6700dec about 20 mA

   – Voltage-read-back Min. Scale at 1500dec

   – Voltage-read-back Max Scale at 6700dec


 The module internally calculated calibration values are:

   – Offset DAC

   – Gain DAC

   – Offset I-read-back

   – Gain I-read-back

   – Offset U-read-back

   – Gain U-read-back


 All calibration values are stored in the module nonvolatile EEPROM.


 Only one channel can be calibrated at a time according to one calibration value (max scale or min scale values).


 The actual date must be transmitted after calibration to the I/O module and stored in the module nonvolatile EEPROM. The data can be read out over the EDT channel.


 The whole calibration can be set to default values by sending a reset command. The default date is Jan,01,2000.


 A specified calibration value can be set to default by sending a reset command for that channel.


 There is a special command to store the whole calibration data from RAM to EEPROM within the I/O module.


 If one value, except the calibration date, isn’t calibrated yet, or if you set one value to default, the I/O module displays a calibration error within the Real Time Data diagnostic field.




Allen Bradley  1794-OE8H


AB  1794OE8H




Email:sales3@amikon.cn



give me a inquiry, i will get you back immediately or in 9 hours.
if you have a large purchase, we can make a discount.

high efficiency application

good quality with long life span

specifications:

new+original +one year warranty






More products --- please contact us !!!
