About product:
The 1769-IQ16F DC high-speed input module is a 16-point input module designed for DC voltage sourcing and sinking. It operates within a voltage range of 10 to 30 Volts DC at an ambient temperature of up to 30°C (86°F), and between 10 to 26.4 Volts DC at a higher ambient temperature of 60°C (140°F). This module is distinct from other I/O modules in the series due to its built-in digital filtering feature, which allows configuration of ON/OFF and OFF/ON delay times of 0 ms, 100 ms, 500 ms, 1 ms, and 2 ms, supporting fast and flexible response rates. The 1769-IQ16F also has a maximum input signal delay of 2 ms (ON to OFF) and 300 ms (OFF to ON). Its power requirements include a current draw of 110 mA at 5.1 Volts DC and a heat dissipation of 3.55 Watts.
Specifications:
|
Parameter
|
Details
|
|
Part Number/Catalog No.
|
1794-OF4I
|
|
Product Description
|
Flex IO High Output Module
|
|
No. of Outputs
|
Four (4) Isolated
|
|
Output Type
|
4-20 mA, 0-20 mA, ±10VDC, 0-10VDC, ±5VDC, 0-5VDC
|
|
Voltage Resolution
|
0.320 mV/cnt
|
|
Current Resolution
|
0.656 mA/cnt
|
|
Terminal Base
|
1794-TB2, 1794-TB3, 1794-TB3S, 1794-TB3T, 1794-TB3TS, 1794-TBN
|
|
External DC Supply (Nom)
|
24V DC
|
|
External DC Supply Range
|
19.2…31.2V DC (includes 5% AC ripple)
|
|
Mounting
|
DIN Rail
|
|
Operating Temperature
|
0 to 55 °C (32 to 131 °F)
|
|
Storage Temperature
|
–40 to 85 °C (–40 to 185 °F)
|
|
Update Rate
|
2.5/5.0 ms (all channels)
|
|
Conversion Type
|
Digital to Analog Converter
|
|
Resolution
|
15 bits plus sign
|
