1794-TB32 | Allen Bradley | Digital Input Module

1794-TB32  Flex I/O Terminal Base Unit has a 0.56-0.79 Nm Terminal Screw Torque



Allen Bradley   1794-TB32  !!!  ---mail to: sales3@amikon.cn



  Email:     sales3@amikon.cn

                                                                     Contact:  Jessica                   |   Skype:     jessica01235483

                                                                     Wechat:   hu18030235311    Mobile:   86-18030235311(WhatsApp)






The 1794-TB32 Flex I/O 24 Volt AC/DC Terminal Base Unit by Allen Bradley is a terminal base unit designed specifically for 32 point modules to provide connection points for input/output wiring. It has a 32 I/O maximum connection capacity, with 8 common terminals and 8 Voltage terminals, and is used in a 31.2 Volt DC application.


It has a current capacity of 10 A, and a FLEXBUS rating of 640 mA and 5 Volts DC, with 2 A maximum I/O terminal rating, and a V/COM terminal rating of 31.2 Volts DC/AC at 50 to 60 Hertz. It is capable of providing 50 Volts circuit isolation with Basic Type insulation tested at 2121 Volts DC for 1 minute between Field-Wiring Terminals to FLEXBUS.




Allen Bradley    1794-TB32

1794-TB32 | Allen Bradley | Digital Input Module




         sales3@amikon.cn




The 1794-TB32 has both IEC T4 and T4A (North America) temperature codes and comes with an open style enclosure. It has an operational temperature range within -20 and 70 degrees Celsius (-4 and 58 degrees Fahrenheit) in a 5% to 95% non-condensing humidity level, and is stored at -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit).
