The 1794-TBNF Terminal Base is a Flex I/O terminal base unit which has a terminal screw torque of 1.4 N-m, and
a supply voltage of 250 Volts AC/DC, at 50 to 60 Hertz, 10 Amps . It has a 250 Volts continuous isolation voltage
at maximum and uses the 0.34 to 3.3 square millimeters wire.
Technical Specifications for 1794-TBNF
Brand / Automation
Series Flex I/O
Part Number 1794-TBNF
Product Type Fused Terminal Base Unit
Product Line Flex I/O 1794
Terminal Screw Torque 1.4 Nm
Supply Voltage 250 V AC/DC
Frequency 50/60Hz
Current Rating 10 A
Maximum Isolation Voltage 250 V (Continuous)
Voltage Rating 24 V DC/AC, 120 V DC/AC, 230 V DC/AC
Wire Size 0.34-3.3 square millimeters
Power Rating 650 W
Operating Temperature -20 to 55 degrees Celsius
