18v 2100mA triac dimmable constant current led driver power supply


SMT-020-2100CT is 2100ma led driver. It is 2100mA constant current triac dimmable led driver for led strip lighting. The output voltage range is 12-20V dc. The wattage is 42W. It has CE ETL FCC ROHS approved for EU and US markets.



  • Size180*60*34mm
  • Dimming modetriac dimming
  • Working Mode42W
  • Output Current2100mA
  • Output Voltage12-20VVdc
  • Input Voltage100-265Vac
  • CertificationCE,ETL ,FCC,RoHS

18v 2100mA triac dimmable constant current led driver power supply


SMT-020-2100CT is 2100ma led driver. It is 2100mA constant current triac dimmable led driver for led strip lighting. The output voltage range is 12-20V dc. The wattage is 42W. It has CE ETL FCC ROHS approved for EU and US markets.


Features of 2100ma led driver


·Output constant current

·Input range :100-130VAC / 170-265VAC

·Built-in PFC function, PF>0.9

·Efficiency > 85%

·Protections:Short circuit/over Voltage

·Fully isolated plastic case

·Easy installation

·Cooling by free air convection

·Work with leading edge and trailing edge TRIAC dimmers

·Strong compatibility, flicker-free dimming

·Suitable for LED lighting and moving sign applications

·Compliance to worldwide safety regulations for lighting

·CE,UL/cUL, RoHS approval

·5 years warranty


Specification of 2100ma led driver:


Model

SMT-120-0350CT



SMT-020-2100CT




SMT-025-1750CT



SMT-050-0900CT


Output

DC Current

350mA

2100mA

1750mA

900mA



Current Accuracy

±5%



Voltage Range

80-120V

12-20V

15-25V

25-50V



Rated power

42W

42W

43W

45W

Input

Voltage Range

 90-130VAC / 170~250VAC



Frequency Range

47~63HZ



Power Factor (Typ.)

PF≧0.93/110V ; PF≧0.95/220V ; PF≧0.94/250V



Full Load Efficiency(Typ.)

>85%

>85%

>85%

>85%



AC Current(Typ.)

0.14A/110VAC  0.12 A/220VAC  0.01A/250VAC



Leakage current

<0.27mA/110VAC; ﹤0.25mA/220VAC

Protection

Short Circuit

Hiccup mode, recovers automatically after fault condition

is removed.



Over voltage

≦270VAC

Environment

Working TEMP.

-40~+60℃



Working Humidity

20~90%RH,non-condensing



Storage TEM.,Humidity

-40~+80℃,10~95%RH



TEMP.coefficient

±0.03%/℃(0~50℃)



Vibration

10~500Hz,2G 10min./1 cycle,period for 60min.

each along X,Y,Z  axes

Safety&EMC

Safety standards

EN-60950-1, EN-61347-1-2



Withstand voltage

I/P-O/P:3.75KVAC



Isolation resistance

I/P-O/P:100MΩ/500VDC/25℃/70%RH



EMC EMISSION

Compliance toEN55015,EN61000-3-2 (≧50%load)



EMC IMMUNITY

Compliance to EN55015,EN61000-4-2,3,4,5,6,8,11,A light industry

level (surge4KV)

Others

Weight

0.34Kg/pcs



Size

180*60*34mm

m

mmm(L*W*H)



packing

324*298*176mm

Notes

1. All parameters NOT specially mentioned are measured at 110V/230VAC input , rated load and

   25℃of ambient temperature.

2. Ripple& noise are measured at 20MHz of bandwidth by using a 12”twisted pair-wire terminated with a

   0.1uf &47uf parallel capacitor.

3.  Tolerance:includes set us tolerance,line regulation and load regulation .


FAQ:



Why do you need a driver for LED lights?

LED drivers also protect LEDs from voltage or current fluctuations. A change in voltage could cause a change in the current being supplied to the LEDs. LED light output is proportional to its current supply, and LEDs are rated to operate within a certain current range (measured in amps).
