Specification
LIGHT SOURCE
Lamp: Lamp: 19pcs*15W RGBW 4 in 1 LED
Lifespan: 50,000H
OPTICS
Beam angle: zoom 10°～60°
COLORS
RGBW
linear color mixing
MOVEMENT
Pan movement: 540° optional (16 bit )
Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth
FEATURES
Dimmer: 0-100% linear electronic
dimmer
Strobe: 1-25Hz or random
Color
change controlled in independent groups, create chasing effect
Built-in
macros function
Electronic dimming, color strobe
effect
General dimming and blackout for all
colors
Perfect pulse and rainbow effect
Smooth RGBW color mixing
DISPLAY
2.4 inch full color LCD screen, show
customer logo
15 second standby auto lock
SOFTWARE
Control mode: DMX512, master-slave,
auto-run, sound activate
Channel: 16CH/24CH
OTHER SPEC
Fixture and lamp usage time display
Highly positioning precision
Built-in analyzer for easy fault finding,
error messages
Input signal isolating protection
Auto thermal protection circuit
Housing: high temperature UV resistant ABS
POWER
Voltage: AC100-240V, 50/60Hz
Power Consumption: 330W@220V
DIMENSIONS AND WEIGHT
Fixture dimension: 29x20x37cm
Packing dimension:
36x24x46cm(Carton)
60x50x55cm(2 in 1 flightcase)
Net Weight: 9.5kg
Gross Weight:
11kg(Carton)
40 kg(2 in 1 flightcase)
