With CE FCC certifificate
|
|
◎ Firmware can be upgraded online
|
|
◎ Suit for USB, RS-232, USB-VCP interface port
|
|
◎ 20 scan lines at a rate of 1,500 scans per second
|
|
◎ Plug and play, no need any driver, easy operation
|
|
Light Source
|
Visible Laser Diode 650nm
|
|
Scan Pattern
|
20 lines 5 fields of 4 parallel lines
|
|
Scan speed
|
1500 scans/s
|
|
Print Contrast
|
30% @ UPC/EAN 100%
|
|
Minimum Resolution
|
4mil
|
|
Depth of Field
|
0-220mm for 0.33mm UPC/EAN100%
|
|
Host System Interfaces
|
USB, RS232,USB-VCP
|
|
Visual Indicators
|
Two color LED (blue & red)
|
|
Beeper Operation
|
Programmable tone & volume
|
|
Cable
|
Standard 2M straight
|
|
Size
|
L × W × H:100mm × 111mm × 147mm
|
|
Weight
|
310g
|
|
Material
|
ABS+PC
|
|
Laser Class
|
5 Volts
|
|
Voltage
|
250mA
|
|
Static Current
|
CE DOC compliance
|
|
EMC
|
- 0°C to 45°C
|
|
Operating Temperature
|
- 20°C to 60°C
|
|
Storage Temperature
|
Designed to 1.5m drops
|
|
Shock
|
|
|
Decoding Capability
|
UPC/EAN/JAN, UPC-A & UPC-E, EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN/ISSN, Code 39 (with full ASCII),
|
|
Codabar (NW7), Code 128 & EAN 128, Code 93, Interleaved 2 of 5 (ITF), Addendum 2 of 5, MSI/Plessy,
|
|
Code 32 (Italian Pharmacode), RSS 14, RSS Limited, RSS Expanded, Industry 2 of 5,Standard 2 of 5.
|
|
Packing dimensions
|
21.5*14.5*11.5CM
|
|
Packaging weight
|
0.665kg
|
|
Carton
|
20pcs/carton 46*38*49CM 14.3KG
|
|
10pcs/carton 55*24*36CM 6.35KG
|
