2.4GHz Omni-directional RFID Reader for Assets Management
2.4GHz Omni-directional RFID Reader for Assets Management
1.MR3202E directional reader is suit for directional identify.
2.MR3202E apply in long distance outdoors/indoors tracking.
3.It's capable of identifying,tracking and orientating more than 200pcs active tags on one time.
4.Omni-directional RFID Reader communicates wirelessly through the antenna and RFID tag.
5.Realizing tag identification and memory data.
6.The 2.4GHz rfid reader is also called reading device,communication device and scanner reader.
7.The electromagnetic clutch is coupled with radar principle.
8.Inductively coupled with transformer model.
Omni-directional RFID Reader Specification
Model No.: MR3202E
Physical property
Material: ABS
Dimension: 92*Φ110mm
Weight: 200g
way to install: wall-mounted,
ceiling fixed
2.4G RF feature
Identify type: Omni-directional,
360 degree covered
Signal modulation
mode: GFSK
Traffic rate: 1Mbit/s
Working frequence:
2440MHz
MAX receive
sensitivity: -90dbm
Antenna Gain: 2dbi，dual polarization
Communication interface
RS232(Baud rate：115200bps；data bits：8；stop bit：1；check bit：N)
RJ45(10/100self-adaption)
Power supply features
Working current:
350mA
Working voltage:
9V DC
Our Advantage
1.0-80 reading range
2.Water proof & Dustproof
3.Easy usage for people tracking
4.Microwave RFID card reader reaches strong penetrability
5.Dual polarization antenna design,ensure RF signal more stable and powerful
6.Long Communication distance and anti-collision performance
7.Strong security,stability and fast read speed reading
Application
1.Fixed Assets real-time Tracking 2. Warehouse Inventory Management 3.Home-school Attendance System
