Speed is 4-10 times faster than the traditional TIG/MIG welding
Easy to operate, no need welding work license, unskilled operator can also weld products beautifully
Can weld metal products of different materials and thicknesses
Low welding heat, no deformation of the workpiece
The welding seam is smooth and beautiful, which reduces the subsequent grinding process and saves time and cost.
Compare with Traditional Welding
Compared to traditional manufacturing processes such as resistance spot welding or conventional ARC welding, PES handheld Fiber Laser Welding offers easy operation, very simple to learn with a fast learning curve, improved energy efficiency, smaller ecological footprint, lower maintenance requirements, less enviremental contamination, improved machine lifetime and faster cycle times for high-volume production.
Consequently, the processing speed is maximized; material costs and operation costs are minimized.
The precision provided by fiber lasers is particularly useful for manufacturers switching to precise, thin-walled and lightweight designs made of light or very resistant materials. Significant weight reduction is achieved by minimizing the size of parts and components via fiber laser welding, while safe engineering is fully enabled by wobble-beam fiber welding.
|
|
Traditional welding
|
Laser welding
|
Welding speed
|
Common
|
4-10x faster
|
HeatAffected zone
|
large
|
small
|
Deformation
|
large
|
small
|
Bond strength with base material
|
Common
|
Excellent
|
Subsequent processing
|
Polish
|
No or very little polish
|
Consumables
|
any
|
Little
|
Operation difficulty
|
Complicate
|
Simple
|
Operator safety
|
Not safe
|
Safe
|
Impact on the environment
|
Pollutional
|
Enviromental
|
Welding fault tolerance
|
Good
|
Good
|
Pendular welding
|
No
|
yes
|
Adjustable spot width
|
No
|
Yes
|
Welding quality contrast
|
Bad
|
Excellent
|
Adjustable Welding mode
|
No
|
Six Mode
|
|
|
PES-W2000 Laser Welding Capacity
Material
|
Thickness
Single side weld
|
Thickness
Double side weld
|
Thickness
Wire weld
|
Sianless steel
|
5mm
|
10mm
|
4.5mm
|
|
Galvanized steel
|
5mm
|
10mm
|
4.5mm
|
|
Mild steel
|
5mm
|
10mm
|
4.5mm
|
Titanium alloy
|
5mm
|
10mm
|
4.5mm
|
|
Aluminum
|
4mm
|
8mm
|
3.5mm
|
|
Copper
|
2mm
|
4mm
|
1.8mm
|
|
|
Lasers
provide non-contact, high-speed metal welding solutions for advanced
manufacturing in countless industries. It can be said that the fiber laser welding machine has become a highly reliable, easily automated
process that provides the highest part quality, often at the lowest
machining cost, and requires little maintenance.
