200mm Pneumatic Battery Edge Folding Machine for Lab
It’s used forlithium battery case edge foldingforming.
Features:
1 Folding width can be adjusted for different battery.
2 Air pressure, speed can be adjusted.
3 Adopted foot switch, Reliable, convenient and quick
4 Small size, simple operation
SPECIFICATIONS
|
Model
|
Battery edge folding machine TMAX-ZP200
|
|
Folding width
|
Adjustable
|
|
Working speed
|
300times/h
|
|
Folding blade length
|
200mm
|
|
Folding width
|
More than 1 mm
|
|
Power supply
|
AC220V/50Hz
|
|
Air pressure
|
0.5～0.8Mpa
|
|
Dimension (L*W*H)
|
320*300*420mm
|
STANDARD PACKAGE LIST
|
Item
|
Qty
|
|
Battery edgefolding machine
|
1 set
|
|
Power line (according to your requirements )
|
1 pcs
|
|
Foot pedal
|
1 pcs
|
|
socket head wrench
|
1 set
|
|
Operating manual (English)
|
1 book
|
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damage part for you for free.
