Features
Compressed air as source of power, program controlled to generate vacuum.
Wholly automatic, auto vacuum and keep for set time at set pressure, auto stop and return.
High speed, high precision.
Can manually pause and stop.
LCD display test data.
Built-in printer can print report with date.
Specifications
Vacuum degree0~-95Kpa
Vacuum precision0.1Kpa
Vacuum keeping time0.01s~9999.9s
Gas sourcecompressed air, 0.7~0.8Mpa
Vacuum chamber sizeΦ270mm × 270mm
Instrument size580mm × 345mm × 440mm
Power100W
Power supplyAC 220V 50Hz
Configuration
Main machine body, power cable, vacuum barrel
User provide: gas source
