Part Number/Catalog No.
|
2080-IF2
|
|
Product Type
|
Analog Plug-in Module
|
|
Module Type
|
Analog
|
|
Number of Single-Ended Inputs
|
2
|
|
Analog Normal Operating Voltage Range
|
0-10V DC
|
|
Analog Normal Operating Current Range
|
0-20mA
|
|
Data Range
|
0-65535
|
|
Repeatability
|
+/- 0.1%
|
|
Update Time
|
180ms per Enabled Channel
|
|
Input Group to Bus Isolation/Channel to Channel Isolation
|
Non-Isolation
|
|
Operating Altitude
|
2000m
|
|
Max. Cable Length
|
10m
|
The 2080-IF2 is an analog input module designed to expand the capabilities of the Micro800 series controllers. It is a plug-in module that integrates seamlessly into the system without increasing its size. The Micro800 system allows customization based on user needs, with support for up to 20 embedded analog inputs.
This module provides 2 single-ended non-isolated inputs, with a voltage range of 0 to 10V DC and a current range of 0 to 20 mA. It features 12-bit unipolar resolution across its entire input range and an overall accuracy of 1% full-scale for both voltage and current, considering factors such as offset, gain, non-linearity, and repeatability. The channel update time is 180ms, and there is no need for field input calibration.
The 2080-IF2 module has 12-pin female terminal blocks for wiring, and the maximum allowable cable length is 10 meters. It can be installed in any slot of the Micro800 controller and is intended for use in clean, dry industrial environments. The operating temperature range is -20°C to 65°C (-4°F to 149°F), with a relative humidity of 5-95% non-condensing, and a maximum operating altitude of 2000 meters.
