Technical specifications for 2080-LC50-24QWB
|
Part Number/Catalog No.
|
2080-LC50-24QWB
|
|
Series
|
Micro 850
|
|
Number of inputs
|
Fourteen (14) 24V inputs
|
|
Number of output
|
Ten (10) Relay outputs
|
|
High-Speed counter (HSC)
|
4 HSC inputs
|
|
Communication ports
|
One (1) USB; One (1) RJ45
|
|
Supported protocols
|
Ethernet I/P; Modbus TCP/IP
|
|
Input voltage
|
24VDC
|
|
Expansion Slots
|
Three (3)
|
|
Maximum I/O supported
|
132 I/O
|
|
Programming language
|
Ladder; Function Block; Structured Text
|
|
No. of Steps / Instructions
|
10K Steps
|
|
Data
|
20K Bytes
|
|
Inputs
|
14
|
|
Input Type
|
12/24V
|
|
Outputs
|
10
|
|
Output Type
|
Relay
|
|
Motion Axis
|
N/A
|
|
HSC
|
4 HSC
|
|
Base Plug-in Slots
|
3
|
|
Base 100KHz HSC max.
|
4 HSC
|
|
Dimensions HxWxD
|
90x145x80 mm
|
|
Expansion I/O Modules
|
Upt to 4 Modules
|
