2094-BM05-S Product Overview:
Observe these guidelines when the 2094-ALxxS, 2094-BLxxS, or 2094-XL75S-Cx LIM module is used in the Bulletin 2094 system and mounted left of the IAM module with the AC (EMC) line filter mounted above the LIM module: • The clean zone (C) is to the right and beneath the Bulletin 2094 system (gray wireway). • The dirty zone (D) is to the left and above the Bulletin 2094 system, and above and below the LIM module (black wireway). • The very dirty zone (VD) is from the filter output to IAM module. Shielded cable is required on the EMC filter (load side) and the braided shield attached to the clamp provided. • The Sercos fiber-optic cables are immune to electrical noise, but due to their delicate nature, route them in the clean zone.
