Technical Specifications for 2098-DSD-HV150-SE
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Bus Overvoltage
|
810V dc
|
|
Part Number/Catalog No.
|
2098-DSD-HV150-SE
|
Input Voltage
|
230...480V rms
|
|
Module Type
|
Servo Drive
|
Relative humidity
|
5 to 95%
|
|
Manufacture Year
|
2021
|
Input Frequency
|
47-63 Hz
|
|
Product Package
|
Original Package
|
UPC
|
821011695714
|
About 2098-DSD-HV150-SE
|
To operate the 2098-DSD-HV150-SE, it must be supplied with an input voltage supply of 3-Phase, 230-480VAC rms. It is capable of providing output power of 7.5 kW at 230VAC and 15.0 kW at 460VAC with Continuous Output Current 34 A and Intermittent Output Current of 68 A.
The 2098-DSD-HV150-SE belongs to the Ultra 3000 Digital Servo Drive that features an integrated SERCOS interface. This SERVO drive is used to control motion and position of actuators such as motors, installed in the manufacturing industry, most of the time in the assembly area.Through the SERCO interface of the drive, communication with controllers installed with the 1756 SERCOS interface module and SoftLogix SERCOS interface installed at the PCI card slot of any programming workstation is possible.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
