Production workflow:
1. Liquid storage:biogas slurry be sent to raw material tank after preprocessing, then be sent to fermentation tank
2. Incculated fermentation: The biogas in fermentation tank be inoculated with specific beneficial organisms and with sufficient stirring and mixing
3. Nutrients adding: Liquid be sent to mixing tank and be added with nutrients
4. Liquid storage: Liquid sent to finish-tank for storage
5. Liquid sent to filling tank
6. Filling and capping
Does this 20L organic liquid fertilizer filling line fits your fertilizer production requirement? Please feel free to contact us for more details and we will help you design the right solution and model set for you.
Notice:
1. provide customized design for special requirement
2. Provide optional device as per actual need
Technical Data:
|
Liquid fertilizer production line
|
|
User interface
|
DN65 (material inlet pressure ＜0.6Mpa)
|
|
Outter diameter of filling head(mm)
|
Φ 40
|
|
Bottleneck size(mm)
|
140*200*320(Min.) 260*290*500(Max.)
|
|
Filling range(kg)
|
5~30
|
|
Weighing accuracy
|
±0.2%
|
|
Filling speed(barrel/h)
|
≤250(5kg)
|
|
Air pressure(Mpa)
|
0.6~0.7
|
|
Air consumption(L/min)
|
120
|
|
Power supply
|
380V
|
Transportation and After-sale Service:
◎All the machine shall be packed in Export wooden box;
◎Engineers are available to do service abroad;
◎Training &Technical instructing lessons shall be provide during installation;
◎Video instruction installation is also available if customer have professional technical engineers;
◎One year warranty is provided for customer.
