20T Lab Manual Cold Isostatic Press Hydraulic CIP Pressing Machine
TMAX-CIP-20J is a CE Certified and the smallest cold isostatic pressing (CIP) machine used for laboratory powder pressing. It has a 30mm ID hydraulic chamber made by ultra strength stainless steel, which can provide isostatic pressure up to 300 Mpa via a 20T manual hydraulic press. It is an excellent tool to prepare high-density compound pellet and small diameter rod. CIP-20J has the small footprint and can be placed in glove-box to prepare air-sensitive materials. A plastic protection cover is included.
Main Features
a).Small size, light weight,No oil, easy to carry.
b).High speed steel imported from Japan
c).Digital display pressure gauge 0.1MPa,Pressure control is more accurate.
d).The oil pool is easy to replace oil on the main surface of the host, and the hydraulic oil filter is added to the oil path.
e).Special plunger, special custom sealed structure, good sealing effect, no oil leakage
f).The upper plate adopts six angle screws in electroplating sunk head. It is beautiful and saves space.
g).One one main plate structure, oil pool, main board, oil cylinder, on one body, no seal connection.
h).Lengthening spring, the rebound effect is good, not easy to deform, can realize the oil cylinder 30mm return no deformation.
i).The Aluminum Alloy handwheel, beautiful, practical, durable, not easy to damage
Specification
|
20T cold isostatic Pressing machine
|
|
Application
|
Laboratory CIP Pressing
|
|
Hydraulic pressing range
|
0~20T(0-21MPa)
|
|
Piston Diameter
|
O.D110mm
|
|
Structure
|
oil tank,machine base No sealing connection, no oil leak point
|
|
Pressure gauge
|
Digital pressure gauge
|
|
Maximum piston distance
|
40mm
|
|
Environment temperature
|
10~40 degree
|
|
CIP Pressure range
|
0~300MPa
|
|
CIP Tank dimension
|
O.D30*120mm
|
|
Outer dimension
|
305*195*600mm
|
|
Gross Weight
|
105Kg
|
Pressure conversion
|
Real Pressure
|
System Pressure
|
Tank inner pressure
|
|
1.7T
|
1.86MPa
|
25MPa
|
|
3.5T
|
3.72MPa
|
50MPa
|
|
5T
|
5.57MPa
|
75MPa
|
|
7T
|
7.43MPa
|
100MPa
|
|
8.7T
|
9.29MPa
|
125MPa
|
|
10.5T
|
11.2MPa
|
150MPa
|
|
14T
|
14.8MPa
|
200MPa
|
|
17.5T
|
18.6MPa
|
250MPa
|
|
21T
|
22.3MPa
|
300MPa
|
Product Images
Machine Parts: Rubber Mold, can be used recycle
Main Features: CIP Stainless steel tank
Machine Parts: Sealing cap
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damage part for you for free.
