The 2198-S086-ERS3 has a control power rating of 4.6A for non-brake servo motors, and 9.6A for brake servo motors and it has a surge of 4A on start-up.
|
|
2198-S086-ERS3 Description:
|
It has a maximum power dissipation at a percentage-rated power output of 190W at 20%, 225W at 40%, 325W at 60%, 300W at 80%, and 475W at 100%.
|
|
The 2198-S086-ERS3 has a functional temperature range between 0 and 50 °C (32 and 122 °F) at 5-95% non-condensing humidity limits and it is designed for storage at -40-70 °C (-40-158 °F) temperature range.
|
|
It is built for installation even at an altitude of 1500m (4921ft) without de-rating and is built to maintain optimal function at an operational vibration of 2G and a shock of 15G.
|
|
