25LPM 5 Chamber Liquid Transer DC Diaphragm Adblue Pumps
Whaleflo Diaphram Adblue pumps and accessories
Suitable for use other liquids from the urea manufacturing process. They are diaphragm pumps with a by-pass Which is designed to dispense products called Ad Blue, AUS32 or water, and also widely used in chemical equipment, agriculture (lawn and garden), carpet cleaning, floor/ground cleaning, and water treatment equipment.
Suitable for IBC transmission systems, permanent magnet pumps work continuously.
Specification
Model Number: HV-25A
Body Materials: Aluminum
Voltage: DC 12V
Current: 10.0A
Pressure off: 60~80PSI
Frequency: 50/60Hz
Flow(Liters/Min):17- 25L(4.5-6.6GPM)
Power: Electric
Pressure Switch: Build in
Speed: 2700rpm
Liquid of Transfer: AdBlue, AUS 32, Water etc.
IP55 Protection, CE
Features&Highlights
Whaleflo Diaphragm Adblue Pump material: aluminum alloy, durable, corrosion resistant, high quality
Permanent magnets and continuous load: maintain a good motor to maintain a stable temperature of the 2m wire plug of the pump body
Whaleflo Self-priming water pump: can be located above the water tank and dry in a short time (up to 20 minutes) without damage
Easy to operate: on/off switch, built-in pressure switch for automatic start or stop when the faucet is opened and closed
Application: Suitable for applications where liquids are transferred from one location to another, such as AdBlue, AUS32 or water etc, spraying, recycling, irrigation and distribution
Note:They must not pump gasoline, chemicals, high viscosity liquids, solvents, etc.
Item Code
|
Volt
|
Flow Rate(L/min)
|
Pressure (PSI)
|
Amps(A)
|
Speed(rpm)
|
|
HV-25A
|
12V DC
|
17-25
|
60-80
|
10.0
|
2700
|
|
HV-25B
|
24V DC
|
17-25
|
60-80
|
6.0
|
2700
|
|
HV-25S
|
115V AC
|
17-25
|
60-80
|
1.5
|
2700
|
|
HV-25M
|
230V AC
|
17-25
|
60-80
|
1.0
|
2700
|
