Traction type

6x4

Driving type

LHD

Cabin

MAN cab, high roof, double sleepers (A/C is optional)

Engine

Brand

Weichai Steyr        EURO II

Model

WD12.420

Type

Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & intercooling

Displacement

11.596 liters

Max. output

420hp@2200rpm

Max torque

1750NM@1300-1600rpm

Bore/Stroke(mm)

126/155

Mean Position Speed

9.53m /s

Compression ratio

15.5:1

Specific fuel consumption

198g /Kwh

Gearbox

Brand

FAST (FULLER technology)

Model

12JS180T  manual operation

Rated input power

331KW

Rated input torque

1800N.m

Max. Input rotation Speed

2600rpm
