The 2711-B6C1 is an Allen-Bradley Panelview 600 terminal that has a 5-inch color display. The user is able to input data using the keypad and touchscreen inputs of the 2711-B6C1.
The 2711-B6C1 allows the operator to connect to other devices by using PanelBuilder 32 software and a remote I/O and by using the RS-232 printer communication port with a 2711-NC13 communication cable.
The 2711-B6C1 is powered using 85-264V AC power. If applicable, this unit has an internal backlight replacement part number of 2711-NL5.
The approximate shipping weight and dimensions of the 2711-B6C1 are 6 lbs. and 14 x 11 x 8 in., respectively. The most common Series are: A, B, C, D, E, F, G, H, I, J, K, and L and the most common firmware include versions 1.00-4.48.
The remote I/O terminals of the 2711-B6C1 terminal can connect to a PLC or an SLC 500 controller (via a 1747-SN module) along with the ControlLogix system (via the 1756-DHRIO) within the 1771 remote I/O system. The application files are downloaded or uploaded using PanelBuilder32 software or by using the remote I/O pass-through, or directly via the onboard RS-232 printing device port, which has a PC memory minute card. The 2711-B6C1 also has 240 KB of nonvolatile memory and 170 KB of RAM.
|
Part Number:
|
|
2711-B6C1
|
|
|
|
|
|
Memory:
|
|
240 KB
|
|
|
|
|
|
Backlight:
|
|
2711-NL3
|
|
|
|
|
|
Communication Cable:
|
|
2711-NC13
|
|
|
|
|
|
Shipping Weight:
|
|
6 lbs.
|
|
|
|
|
|
Shipping Dimensions:
|
|
14 x 11 x 8 in
|
|
|
|
|
|
Series:
|
|
A, B, C, D, E, F, G, H, I, J, K, and L
|
|
|
|
|
|
Firmware:
|
|
1.00-4.48
|
Allen Bradley 2711-B6C1
2711-B6C1 - Allen Bradley | PanelView 600 Color Terminals
Email:sales3@amikon.cn
Part Number:
|
2711-B6C1
|
|
Product Line:
|
Panelview 600
|
|
Input Type:
|
Keypad/Touchscreen
|
Communication:
|
Remote I/O and RS-232 Printer
|
|
Input Power:
|
85-264 VAC
|
