Manufacturer Automation
Input Type Touch
Part Number/Catalog No. 2711-T10C15
Brand
Product Family: PanelView Standard Terminals
Product Type: Operator Terminals
Display Type: Active Matrix Thin-Film Resistor (TFT) with Cold Cathode Fluorescent (CCF) Backlight
Display Area: 211 x 158 mm (8.3 x 6.2 in.)
Resolution: 640 x 480 pixels
Backlight: 100,000 hr LED backlight life
Touchscreen: 384 (24 columns x 16 rows)
Touch Cell size: 26 x 30 pixels
Application memory: 1008K bytes (application screens)
Communication ports: ControlNet; RS232 (printer)
Input Voltage range: 85-264VAC
Operating Temperature: 0…55 ° C (32…131 ° F)
Power Consumption: 39 W (132 BTU/HR)
Product Line Panelview 1000
Display Size 10.1 inches
Display Color Multi-Color
Communication Printer (RS-232) Port and ControlNet
Input Power 85 to 264 Volts AC
Memory 256 Kilobytes
Enclosure Type NEMA Type 12/13 or 4x
UPC 10662072759315
UNSPSC 43211903
Product Lifecycle Status* Discontinued/Obsolete
