All the waterproof led power supply 12v are Constant voltage design, and meet UL CE ROHS FCC approved. Can be compatible with multiple brand lamps, such as Stouch Lighting High bay lighting high ceilings.
Specification
|
model
|
SMT-012-080VDHW
|
SMT-024-080VDHW
|
|
Output
|
DC Voltage
|
12V
|
24V
|
|
Voltage Accuracy
|
±0.5V
|
|
Rated current
|
6.66A
|
3.33A (class 2 type)
|
|
Rated power
|
80W
|
80W
|
|
Input
|
Voltage Range
|
100~277V AC
|
|
Frequency Range
|
47~63HZ
|
|
Power Factor ( Typ.)
|
PF≧0.95/110V , PF≧0.95/277V
|
|
Full Load Efficiency(Typ.)
|
86%@120VAC 88%@277VAC
|
|
AC Current(Typ.)
|
1.3A @110VAC 0.72A/170VAC 0.530A/220VAC 0.427A/277VAC
|
|
Inrush Current (Typ.)
|
1.0A/120VAC 0.63A/170VAC 0.50A/220VAC 0.41A/277VAC
|
|
Leakage current
|
﹤0.40mA/110V,277VAC
|
|
Protection
|
Short Circuit
|
Hiccup mode, recovers automatically after fault condition is removed.
|
|
Over voltage
|
≦140VAC(90~135V) , ≦290VAC(260~277V)
|
|
Environment
|
Working TEMP.
|
-40~+60℃
|
|
Working Humidity
|
20~90%RH,non-condensing
|
|
Storage TEM.,Humidity
|
-40~+80℃,10~95%RH
|
|
TEMP.coefficient
|
±0.03%/℃(0~50℃)
|
|
Vibration
|
10~500Hz,2G 10min./1 cycle,period for 60min.each along X,Y,Z axes
|
|
Safety&EMC
|
Safety standards
|
Class P, Type HL, EN61347-1 EN61347-2-13 IP67
|
|
Withstand voltage
|
I/P-O/P:3.75KVAC I/P-FG:1.88KVAC O/P-FG:0.5KVAC
|
|
Isolation resistance
|
I/P-O/P I/P-FG O/P-FG:100MΩ/500VDC/25℃/70%RH
|
|
EMC EMISSION
|
Compliance to EN55015,EN61000-3-2 (≧50%Load)
|
|
EMC IMMUNITY
|
Compliance to EN61000-4-2,3,4,5,6,8,11,EN61547,Alight industry level (surge4KV)
|
|
Others
|
Weight
|
1.32Kg
|
|
Size
|
230*70*47mm(L*W*H)
|
|
packing
|
329*279*176mm/10pcs
|
|
Notes
|
1. All parameters NOT specially mentioned are measured at 120VAC & 277vac input , rated load and 25℃of ambient temperature.
|
|
2. Ripple& noise are measured at 20MHz of bandwidth by using a 12”twisted pair-wire terminated with a 0.1uf &47uf parallel capacitor.
|
|
3. Tolerance:includes set us tolerance,line regulation and load regulation .
|
Compatible Light Type
UL listed dimmable waterproof led power supply 12v 80w ,the universal AC input:100-277vAC. It is often used in large indoor spaces like factories and distribution facilities with Stouch Lighting High bay lighting.
