277Vac UL 12V dc 80W 0-10V dimmable led driver power supply
Our SMT-012-080VDH is high quality UL led driver power supply with high PF>0.95 high Efficiency>90%. Driver and junction box in one case which you do not need pruchase junction box anymore. This model is IP20 non-dimmable led driver.
Features of UL led driver power supply
Output constant voltage type
·Range 100-305VAC , Typical: 100-277VAC
·Built-in PFC function PF>0.90
·Efficiency > 88%
·Protections:short circuit/over current/over voltage/over temperature
·Cooling by free air convection
·IP20 design for indoor or outdoor installations .
·Dimming function:0-10V/ 1-10V/ 10VPWM signal or resistance .
·Suitable for LED lighting and moving sign applications
·Compliance to worldwide safety regulations for lighting
·Suitable for dry/damp locations
·7 years warranty
Specification of UL led driver power supply
|
model
|
SMT-012-080VDH
|
SMT-024-080VDH
|
|
Output
|
DC Voltage
|
12V
|
24V
|
|
|
Voltage Accuracy
|
±0.5V
|
|
|
Rated current
|
6.66A
|
3.33A (class 2 type)
|
|
|
Rated power
|
80W
|
80W
|
|
Input
|
Voltage Range
|
100~277V AC
|
|
|
Frequency Range
|
47～63HZ
|
|
|
Power Factor ( Typ.）
|
PF≧0.95/110V , PF≧0.95/277V
|
|
|
Full Load Efficiency(Typ.)
|
86%@120VAC 88%@277VAC
>85%
|
|
|
AC Current（Typ.）
|
1.3A @110VAC 0.72A/170VAC 0.530A/220VAC 0.427A/277VAC
|
|
|
Inrush Current （Typ.）
|
1.0A/120VAC 0.63A/170VAC 0.50A/220VAC 0.41A/277VAC
1.0A/120VAC 0.63A/170VAC 0.50A/220VAC 0.41A/277VAC
|
|
|
Leakage current
|
﹤0.40mA/110V,277VAC
|
|
Protection
|
Short Circuit
|
Hiccup mode, recovers automatically after fault condition
is removed.
|
|
|
Over voltage
|
≦140VAC(90~135V) , ≦270VAC(170~265V)
|
|
Environment
|
Working TEMP.
|
-40～+60℃
|
|
|
Working Humidity
|
20～90%RH,non-condensing
|
|
|
Storage TEM.,Humidity
|
-40～+80℃，10～95%RH
|
|
|
TEMP.coefficient
|
±0.03%/℃（0～50℃）
|
|
|
Vibration
|
10～500Hz，2G 10min./1 cycle，period for 60min.
each along X,Y,Z axes
|
|
Safety&EMC
|
Safety standards
|
UL8750+UL1310
|
|
|
Withstand voltage
|
I/P-O/P:3.75KVAC
|
|
|
Isolation resistance
|
I/P-O/P:100MΩ/500VDC/25℃/70%RH
|
|
|
EMC EMISSION
|
FCC Part 15 B
|
|
Others
|
Weight
|
1.3Kg
|
|
|
Size
|
220*93*41mm (L*W*H)
|
|
|
packing
|
10PCS/CTN
385*335*200mm 20PCS/CTN
|
|
Notes
|
1. All parameters NOT specially mentioned are measured at 110V/277VAC input , rated load and 25℃of ambient temperature.
2. Ripple& noise are measured at 20MHz of bandwidth by using a 12”twisted pair-wire terminated with a 0.1uf &47uf parallel capacitor.
3. Tolerance:includes set us tolerance,line regulation and load regulation .
|
Mechanical Specification
FAQ
What is the advantages of your 0-10V dimmable led driver?
Answer:
-- the dimming range of other brand 0-10v dimmable led drivers is 1%-100%, but Smarts’ 0-10v dimmable led driver can be 0%. And it do not have the flicker issue.
-- Other brand 0-10v dimmable led driver achieve dimming function though adjust the output current and it has the min load limitation. But Smarts’ 0-10v dimmable led driver is adjust the output voltage to achieve dimming function.
-- What is more, Smarts Electronics’ 0-10v dimmable led driver do not have min load limitation. That is to say, you do not consider the load limitation when you choose our led driver.
-- Our 0-10v dimmable led driver has passed the ETL FCC CE Rohs listed and has 7 years warranty.
