(1) Adopt the advanced EL air tight system in the world to maintain high vacuum. Gas-liquid separation, no reflux.
(2) The rotating bottle is connected with the nut for ease of loading and unloading.
(3) Collecting bottles with a discharge valve at the bottom, and recovering the solvent quickly.
(4) Vacuum system is equipped with vacuum gauge to adjust the best working vacuum degree for low boiling point material.
(5) The water bath pot is controlled by electronic constant temperature and can be lifted up or down.
(6) The structure is reasonable and the material is exquisite.
|
Model
|
OLT-RE-5
|
|
Motor
|
Electrocution button
|
|
Speed of rotating
|
20-200r/min
|
|
Heating groove
|
PTFE compound pan, full closed heater,1.4KW
|
|
Lifting
|
Fast automatic lifting,0-150mm
|
|
Range of temperature regulation
|
Room temperature-90℃
|
|
Feeder
|
Valve type feeding tube casting with PTFE tube
|
|
Sealing
|
Fluoro rubber vacuum sealing gasket
|
|
Condenser
|
Vertical, high temperature resistant
high quality glass refining double reflux integrated standard port
condenser pipe connection standard
grinding collecting bottle
|
|
Total power
|
1.5KW
|
|
Voltage
|
108V-220V
|
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
