Dimensions :
|
DIMENSIONS
|
|
Tare weight
|
12000kg
|
Payload
|
60000kg
|
|
Overall Length
|
13000mm
|
Overall Width
|
3000mm
|
Overall height
|
1250mm
|
Specification :
|
SPECIFICATION
|
|
Chassis
|
Heavy duty and extra durability designed i beam；opting
for high tensile steel Q345，welded
by automatic subrnerged-Arc processes. Top plate 20mm.bottom plate 20mm.middle plate 14mm.height 500mm
|
|
Axle
|
Number
|
3
|
Brand
|
Optional upon choice
|
Capacity
|
13T
|
|
Suspension
|
Mechanical suspension Or air suspension
|
|
Leaf spring
|
Leaf spring or air bag
|
|
Floor
|
checkered plate
|
|
Tire
|
11.00R20，12.00R20，11R22.5，12R22.5，315/80R22.5
Tire optional
|
|
Wheel rim
|
8.5-20，9.0-20,8.25-22.5,9.0-22.5 steel
wheel rim optional upon choice
|
|
Kingpin
|
2”/3.5”bolt-in king pin
|
|
Landing gear
|
JOST brand two-speed，manual operation，heavy
duty landing gear
|
|
Ladder
|
Mechanical
ladder
|
|
Vehicular applications
|
Machine transport
|
|
Braking system
|
WABCO RE6 relay valve；T30/30 sping brake chamber；40L
air tanks
|
|
Painting
|
Complete chassis sand blasting to clean rust，1coat
of anticorrosive prime，2coats of final paint
|
|
Accessories
|
One standard tool box
|
