30° - 60° - 90° Littrow Dispersion Prisms

Dispersion Prisms are used in applications that require separating the incident light into its component wavelengths. For example, when white light enters a Dispersion Prism, it is separated into its three components: red, green, and blue. Dispersion Prisms are ideal for spectroscopy or laser tuning.



1. What is dispersion prism?



A dispersive prism is an optical prism, usually having the shape of a geometrical triangular prism, used as a spectroscopic component.


2. What’s the main application of dispersion prism?



Dispersion Prisms used in applications such as spectroscopy or laser tuning.



3. Are the dispersion prism can used in IR application?


Yes, the dispersion prisms are also available in multiple substrates that are ideal for Infrared (IR) applications.


Dispersion Prisms  Dispersion Prisms


Specifications:

Material:  N-BK7, N-SF11 Grade A optical glass, UV grade fused silica
Angle:  θ=60°
Angle tolerance:  ±3 arcmin
Dimensional tolerance: +/-0.1mm
Surface quality:  40-20
Flatness: λ/4@632.8nm
Clear Aperture: >80%
Bevel:  Protective
Coating:  Optional


Typical Sizes:


Part NO. A=B=C(mm) H(mm) θ
UDPP001 15 15 60°
UDPP002 20 20 60°
UDPP003 25.4 25.4 60°
UDPP004 30 30 60°
UDPP005 38.1 38.1 60°
UDPP006 50.8 50.8 60°
