300*200mm Size Lithium Ion Battery Copper Foil 10um
SPECIFICATIONS
Width:200mm Lenght: 300m Thicness:10um
Mode:T-C10-300*200mm
|
Copper foil for battery anode substrate
|
|
Item
|
Data
|
|
width (mm)
|
300mm
|
|
Thickness (um)
|
10
|
|
areal density (g/m2)
|
95-100
|
|
Purity(%) More than 99.9%
|
Cu ≥99.9%
|
|
Fe < 0.0010%
|
|
Bi < 0.00020%
|
|
Pb < 0.0005%
|
|
Tensile strength (MPa)
|
≥300
|
|
Normal elongation(%)
|
2.7
|
|
High temperature Tensile strength180℃(MPa)
|
≥150
|
|
High temperature elongation180℃(%)
|
2
|
|
Anti oxidization(180℃ Heating 1h)
|
No oxidation of points on the surface,The color does not change,Copper
foil without fracture
|
|
Surface roughness(um)Rz
|
Drum side(um)
|
Less than 0.3
|
|
Matte side(um)
|
Less than 3.5
|
|
Surface tension(dyne/cm)
|
Drum side
|
65
|
|
Matte side
|
65
|
|
Coating performance
|
Cu foil with uniform tension on both sides, slurry coating uniformity
|
