300mm Width Lithium Battery Coating Machine With 6M Baking Oven
Thelithium battery coating machine TOB-LIC-300 model coating machine is mainly used for Slurry drying process of lithium battery electrode coating.
Thisbattery electrode coating machineadopts interval and continuous coating mode, it can coat electrode with fixed width and length For winding process or stacking process.
Equipped with 3 sections baking oven for 6M length, can dry the electrode in a higher speed, it is mainly used for battery pilot scale producing and research.
SPECIFICATIONS
|
Model
|
Battery Coating Machine TOB-LIC300
|
|
Source voltage
|
AC 220V/110V, 50/60HZ
|
|
Warranty
|
One year limited warranty with lifetime support
|
|
Suitable material width
|
Aluminum foil : 150-300mm, Copper foil : 150-300mm
|
|
Suitable material thickness
|
Aluminum foil : 11-30um, Copper foil : 9-30um
|
|
Suitable material diameter
|
350mm
|
|
Suitable material weight
|
300kg
|
|
Coating thickness
|
Cathode : 50-150um, Anode : 60-180um
|
|
Coating gap length
|
5-500mm
|
|
Coating length
|
50-3500mm
|
|
Coating speed
|
Max 3m/min
|
|
Machine speed
|
1.5-5m/min
|
|
Oven length
|
2m/section, 3 section ovens
|
|
Coating accuracy
|
Hangover
|
≤ ±1mm, according to the slurry performance
|
|
Head, Tail, Border
|
≤ 5mm
|
|
Length error
|
≤ ±0.75mm
|
|
Coating width error
|
≤ ±0.5mm
|
|
Thickness error
|
-15-5um
|
