Model
|
d
/mm
|
D
/mm
|
T
/mm
|
B
/mm
|
C
/mm
|
r
/mm
|
|
da
/mm
|
Da
/mm
|
Cr
/kN
|
C0r
/kN
|
nlim
/r•min-1
|
nlim
/r•min-1
|
|
30203
|
15
|
35
|
11.8
|
11
|
10
|
0.6
|
0.23
|
20
|
30
|
—
|
—
|
—
|
—
|
|
30302
|
15
|
42
|
14.3
|
13
|
11
|
1
|
0.19
|
21
|
36
|
22.8
|
21.5
|
9000
|
12000
|
|
30203
|
17
|
40
|
13.3
|
12
|
11
|
1
|
0.23
|
23
|
34
|
20.8
|
21.8
|
9000
|
12000
|
|
32203
|
17
|
40
|
17.3
|
16
|
14
|
1
|
0.21
|
23
|
34
|
—
|
—
|
—
|
—
|
|
30303
|
17
|
47
|
15.3
|
14
|
12
|
1
|
0.19
|
23
|
41
|
28.2
|
27.2
|
8500
|
11000
|
|
32303
|
17
|
47
|
20.3
|
19
|
16
|
1
|
0.19
|
23
|
41
|
35.2
|
36.2
|
8500
|
11000
|
|
32904
|
20
|
37
|
12
|
12
|
9
|
0.3
|
0.21
|
22.4
|
34.6
|
13.2
|
17.5
|
9500
|
13000
|
|
32004
|
20
|
42
|
15
|
15
|
12
|
0.6
|
0.25
|
25
|
37
|
25
|
28.2
|
8500
|
11000
|
|
30204
|
20
|
47
|
15.3
|
14
|
12
|
1
|
0.23
|
26
|
41
|
28.2
|
30.5
|
8000
|
10000
|
|
32204
|
20
|
47
|
19.3
|
18
|
15
|
1
|
0.22
|
26
|
41
|
—
|
—
|
—
|
—
|
Tapered roller bearings 30303 are separate bearings. Both the inner and outer rings of the bearing have tapered raceways. This type of bearing is divided into single, double and four-row tapered roller bearings according to the number of rollers installed. Single-row tapered roller bearings can support radial loads and axial loads in one direction. When the bearing is subjected to a radial load, an axial component will be generated, so when another bearing that can bear the axial force in the opposite direction is needed to be balanced.
The single-row tapered roller bearing's ability to withstand axial load depends on the contact angle, that is, the outer ring raceway angle. The larger the angle, the greater the axial load capacity. The most used tapered roller bearings are single-row tapered roller bearings. In the front wheel hub of the car, a small double-row tapered roller bearing is used. Four-row tapered roller bearings are used in heavy machines such as large cold and hot rolling mills.
The outer ring (or inner ring) of a double-row tapered roller bearing is a whole. The two small inner end faces of the inner ring (or outer ring) are close to each other, and there is a spacer in the middle. The clearance is adjusted by the thickness of the spacer. The thickness of the spacer can also be used to adjust the pre-interference of the double-row tapered roller bearing.
