3300 XL 8 mm Proximity Probes, Metric:
330103 3300 XL 8 mm Probe, M10 x 1 thread, withoutarmor2
330104 3300 XL 8 mm Probe, M10 x 1 thread, witharmor2
Part Number-AXX-BXX-CXX-DXX-EXX
A: Unthreaded Length Option
Order in increments of 10 mm.
Length configuration:
Maximum unthreaded length: 230mm
Minimum unthreaded length: 0 mm
Example: 0 6 = 60 mm
B: Overall Case Length Option Order in increments of 10 mm. Metric thread configurations: Maximum length: 250 mm
Minimum length: 20 mm Example: 0 6 = 60 mm
C: Total Length Option
0 5 0.5 metre (1.6 feet)
1 0 1.0 metre (3.3 feet)
1 5 1.5 metres (4.9 feet)
2 0 2.0 metres (6.6 feet)
5 0 5.0 metres (16.4 fee
9 0 9.0 metres (29.5 feet)
D: Connector and Cable-Type Option
0 1 Miniature coaxial ClickLoc
connector with connector
protector, standard cable
0 2 Miniature coaxial ClickLoc
connector, standard cable
1 1 Miniature coaxial ClickLoc
connector with connector
protector, FluidLoc cable
1 2 Miniature coaxial ClickLoc
connector, FluidLoc cable
E: Agency Approval Option
0 0 Not required
0 5 CSA, ATEX, IECEx Approvals
|
