330104-00-13-10-02-05 | Bently Nevada | extension cable

Bently Nevada    330104-00-13-10-02-05   !!!  --- sales3@amikon.cn

  Contact:  Jessica

                               Email:

                               Skype:  jessica01235483

                               Wechat:  hu18030235311

                               Mobile:  86-18030235311(WhatsApp)

An Extended Temperature Range (ETR) Probe and Extension Cable are available for applications where either the probe lead or extension cable may exceed the 177 °C (350 °F) temperature specification. The Extended Temperature Range Probe has an extended temperature rating for up to 260 °C (500 °F) for the probe lead and connector. The probe tip must remain below 177 °C (350 °F). The Extended Temperature Range Extension Cable is also rated for up to 260 °C (500 °F). Both the ETR probe and cable are compatible with standard temperature probes and cables. For example, you can utilize an ETR probe with the 330130 extension cable. The ETR system uses the standard 3300 XL Proximitor Sensor. When using any ETR component as part of your system, the accuracy is limited to the accuracy of the ETR system.

8 mm probes provide a thicker encapsulation of the probe coil in the molded PPS plastic probe tip. This results in a more rugged probe. The larger diameter of the probe body also provides a stronger, more robust case. Bently Nevada recommends the use of 8 mm probes when possible to provide optimal robustness against
physical abuse.

Bently Nevada   330104-00-13-10-02-05

330104-00-13-10-02-05 | Bently Nevada | extension cable

Email:sales3@amikon.cn

Silicone tape is also provided with each 3300 XL extension cable and can be used instead of connector protectors. Silicone tape is not recommended in applications where the probe-toextension cable connection will be exposed to turbine oil.

HOT SALE --- please contact us !!!

Emal:sales3@amikon.cn

Shipping Term : TNT,DHL,FEDEX,ETC
Payment Term : T/T

Warranty: 12 month
Amikon supply： New+original+factory sealed+high quality

Service: quotation will be sent in 9 hours
Skype + whatsapp + mobile  =  24 hours /day   Oneline.
