330730-080-01-00 | Bently Nevada | extension cable

Bently Nevada    330730-080-01-00   !!!  --- sales3@amikon.cn

  Contact:  Jessica

                               Email:

                               Skype:  jessica01235483

                               Wechat:  hu18030235311

                               Mobile:  86-18030235311(WhatsApp)

The 3300-series 5 mm probe (refer to Specifications and Ordering Information document 141605) uses smaller physical packaging, but does not reduce the side
view clearances or tip-to-tip spacing requirements as compared to an 8mm probe. It is used when physical (not electrical) constraints preclude the use of an 8mm
probe. When your application requires narrow side view probes, use the 3300 NSv* Proximity Transducer System (refer to Specifications and Ordering Information
document 147385).

8 mm probes provide a thicker encapsulation of the probe coil in the molded PPS plastic probe tip. This results in a more rugged probe. The larger diameter of
the probe body also provides a stronger, more robust case. We recommend that you use 8 mm probes when possible to provide optimal robustness against physical
abuse.

Each 3300 XL extension cable includes silicone tape that you can use instead of connector protectors. We do not recommend silicone tape for applications that will
expose the probe-to-extension cable connection to turbine oil

Bently Nevada   330730-080-01-00

330730-080-01-00 | Bently Nevada | extension cable

Email:sales3@amikon.cn

0.2 to 1.5 mm2 (16 to 24 AWG) . Recommend using 3 conductor shielded triad cable and tinned field wiring. Maximum length of 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and the monitor. See the frequency response graphs, Figures 10 and 12, for signal rolloff at high frequencies when using longer field wiring lengths.
