3500/15 | Bently Nevada | Power Supply

The 3500 Power Supplies are half-height modules and must be installed in the specially designed slots on the left side of the rack.











Bently Nevada    3500/15  !!!  --- sales3@amikon.cn



  Contact:  Jessica

                               Email:  sales3@amikon.cn

                               Skype:  jessica01235483

                               Wechat:  hu18030235311

                               Mobile:  86-18030235311(WhatsApp)








The 3500 Power Supplies are half-height modules and must be installed in the specially designed slots on the left
side of the rack. The 3500 rack can contain one or two power supplies (any combination of ac and/or dc) and either supply can power a full rack. If installed, the second supply acts as a backup for the primary supply. When two power supplies are installed in a rack, the supply in the lower slot acts as the primary supply and the supply in the upper slot acts as the backup supply. Removing or inserting either power supply module will not disrupt operation of the rack as long as a second power supply is installed.





The 3500 Power Supplies accept a wide range of input voltages and converts them to voltages acceptable for use by other 3500 modules. Three Power Supply versions are available with the 3500 Series Machinery Protection System as follows:


1. ac Power Supply
2. High Voltage dc Power Supply
3. Low Voltage dc Power Supply






Bently Nevada   3500/15


3500/15 | Bently Nevada | Power Supply






Email:sales3@amikon.cn






Voltage Options:
175 to 264 Vac rms:  (247 to 373 Vac, pk), 47 to 63
Hz. This option uses the ac
Power Supply and the High
Voltage ac (220 V nominal)
Power Input Module (PIM).
Installations using AC Power Input Modules (PIM) prior to
rev R and/or AC Power Supply Module prior to rev M
require voltage input:: 175 to 250 Vac rms
85 to 132 Vac rms:  (120 to 188 Vac, pk), 47 to 63
Hz. This option uses the ac
Power Supply and the Low
Voltage ac (110 V nominal)
Power Input Module (PIM).
Installations using AC Power Input Modules (PIM) prior to
rev R and/or AC Power Supply Module prior to rev M
require voltage input:: 85 to 125 Vac rms
