The Rack Interface Module (RIM) is the primary interface into the 3500 rack. It supports a Bently Nevada proprietary protocol used to configure the rack and retrieve machinery information. The RIM must be located in slot 1 of the rack (next to the power supplies). The RIM provides the connections needed to support current Bently Nevada Communications Processors (Transient Data Interface External (TDIX) and Dynamic Data Interface External (DDIX)). Although the RIM does provide certain functions common to the entire rack, the RIM is not part of the critical monitoring path. The RIM's operation (or nonoperation) has no effect on the proper, normal operation of the overall monitoring system.





This indicates if the Rack Interface Module is functioning correctly. A not OK status is returned under any of the following conditions:


• Hardware Failure in the module

• Node Voltage Failure

• OK Relay coil check Failed






Bently Nevada   3500/20


3500/20 | Bently Nevada | RACK INTERFACE MODULE






Email:sales3@amikon.cn







The Rack Interface Module uses two I/O module types, the Rack Interface I/O Module and the Data Manager I/O Module. These I/O modules let you connect a 3500 host computer and Communication Processors (TDIX or DDIX) to a 3500 rack and let you daisy chain racks together.



This section describes how to use the connectors on the I/O modules, lists what cables to use, and shows the pin outs of the cables.
