3500/50 133388-02 | Bently Nevada | Tachometer Module

The 3500/50 Tachometer Module is a 2-channel module that accepts input from proximity probes or magnetic



Bently Nevada    3500/50 133388-02  !!!  --- sales3@amikon.cn



  Contact:  Jessica

                               Email:  sales3@amikon.cn

                               Skype:  jessica01235483

                               Wechat:  hu18030235311

                               Mobile:  86-18030235311(WhatsApp)








The 3500/50 Tachometer Module is a 2-channel module that accepts input from proximity probes or magnetic pickups (except as noted) to determine shaft rotative speed, rotor acceleration, or rotor direction, compares these measurements against user-programmable alarm setpoints, and generates alarms when these setpoints are violated. The 3500/50 Tachometer Module is programmed using the 3500 Rack Configuration Software and can be configured with four different options:




1. Speed Monitoring, Setpoint Alarming, and Speed Band Alarming.

2. Speed Monitoring, Setpoint Alarming, and Zero Speed Notification.

3. Speed Monitoring, Setpoint Alarming, and Rotor Acceleration Alarming.

4. Speed Monitoring, Setpoint Alarming, and Reverse Rotation Notification.





The 3500/50 can be configured to supply conditioned Keyphasor® signals to the backplane of the 3500 rack for use by other monitors, thus eliminating the need for a separate Keyphasor® module in the rack. The 3500/50 also has a peak hold feature that stores the highest speed, highest reverse speed, or number of reverse rotations (depending on channel type selected) that the machine has reached. These peak values can be reset by the user.






Bently Nevada   3500/50 133388-02


3500/50 133388-02 | Bently Nevada | Tachometer Module






Email:sales3@amikon.cn






Signal: Each Tachometer Module accepts up to
two transducer signals from proximity
probe transducers or magnetic pickups.
The input signal range is +10.0 V to -24.0
V. Signals exceeding this range are
limited internally by the module.
Input Impedance: 20 k Ω (standard);
40 kΩ (TMR);
7.15 kΩ (Internal Barrier).
Power Consumption: 5.8 Watts, typical.
Transducers: Accepts 1-2 proximity transducer signals.















HOT SALE --- please contact us !!!




Bently NEVADA  3300/48-04-02-01-00
Bently NEVADA  3300/50-02-01-00-00
Bently NEVADA  3300/50-02-02-00-00
Bently NEVADA  3300/55-01-04-02-02-00-00-04-00
Bently NEVADA  3300/55-01-04-12-12-00-00-05-00
Bently NEVADA  3300/55-01-05-02-02-00-00-09-00
Bently NEVADA  3300/55-01-05-12-12-00-00-05-00
Bently NEVADA  3300/61-03-01-01-00-00-00
Bently NEVADA  3300XL extension cable1
Bently NEVADA  330130-045-00-00
Bently NEVADA  330930-045-00-05
Bently NEVADA  330930-065-00-05
Bently NEVADA  330930-065-03-05








Emal:sales3@amikon.cn






if you have a large purchase, we can make a discount.
specifications:

new+original +one year warranty


we supply:

plc : ab,abb,ge,schneider
dcs : abb,siemens moore,foxboro,westinghouse,yokogawa
esd : triconex,hima,bently,ics
excitation cards : abb,ge marke
