3500/70M 136449-09 | Bently Nevada | Recip Impulse/Velocity Monitor

The primary purpose of the 3500/70M Recip Impulse/Velocity Monitor



Bently Nevada    3500/70M 136449-09  !!!  --- sales3@amikon.cn



  Contact:  Jessica

                               Email:  sales3@amikon.cn

                               Skype:  jessica01235483

                               Wechat:  hu18030235311

                               Mobile:  86-18030235311(WhatsApp)








The 3500/70M Recip Impulse/Velocity Monitoris a 4-channel device used as part of the reciprocating compressor solutions package to monitor compressor crankcase and crosshead vibration. The monitor accepts input from seismic transducers, conditions the signal to derive vibration measurements, and compares the conditioned signals with user-programmable alarms.




You can program each channel using the 3500 Rack Configuration Software to perform the following functions:



  • Impulse Acceleration
  • Acceleration 2
  • Recip Velocity
  • Low Frequency Recip Velocity





Each channel, depending on configuration, typically conditions its input signal to generate various parameters called measured variables. You can configure alert setpoints for each active measured variable and danger setpoints for any two of the active measured variables.







Bently Nevada   3500/70M 136449-09


3500/70M 136449-09 | Bently Nevada | Recip Impulse/Velocity Monitor






Email:sales3@amikon.cn






Signal Accepts from 1 to 4 velocity
or acceleration transducer signals
Input Impedance 10 kΩ acceleration input
>1 MΩ velocity input
330500 Velomitor* Piezo-Velocity Sensor
330525 Velomitor XA Piezo-Velocity Sensor
190501 Velomitor CT Velocity Transducer
Sensor compatibility 330400 Accelerometer Acceleration
Transducer
330425 Accelerometer Acceleration
Transducer
Special inhibit Contact closure
5 Vdc @ 390μA typical
Power Consumption  7.7 watts, nominal
