Specification
LIGHT SOURCE
Lamp: YODN MSD 350W
CT: 7500K
Lifespan: 2,000H
OPTICS
Zoom range: 2.4°–38°
High precision glass optic system
Improved optics and flat beam field
COLORS
1 Color wheel: 14 color+open
Half-color effect, linear color change, bidirectional rotating rainbow
effect
GOBOS
1 Static gobo：16 gobos+open, shakable and bi-directionally
rotatable at variable speeds
1 Rotating gobo： 12 gobos +open, shakable
and bi-directionally rotatable at variable speeds
MOVEMENT
Pan movement: 540° optional (16 bit )
Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth
FEATURES
2 Prisms: 16-facet+32-facet, bi-directionally rotatable at variable
speeds
Frost: 1 frost filter, soft and natural
wash effect
Strobe: mechanical shutter , variable from
1-20Hz or random
Dimming: mechanical dimmer 0-100% linearly adjustable
Focus: motorized
linear focus
Zoom range:
Beam mode 2.4°- 20°
Spot mode 8°- 32°
Wash mode 10°- 38°
DISPLAY
2.8 inch full color touch LCD screen, show
customer logo
15 second standby auto lock
SOFTWARE
Control mode: DMX512, master-slave,
auto-run, sound activate
Channel: 16/24 /30CH
Run
time of lamp and fixture record
OTHER SPEC
Fixture and lamp usage time display
Highly positioning precision
Adjustable fan speed
Built-in analyzer for easy fault finding,
error messages
Input signal isolating protection
Auto thermal protection circuit
Housing: high temperature UV resistant ABS
POWER
Voltage: AC100-240V, 50/60Hz
Power Consumption: 540W@220V
DIMENSIONS AND WEIGHT
Fixture dimension: 38*27*56cm
Packing dimension:
65x42x42cm(Carton)
86x40x78cm(2 in 1 flightcase)
Net Weight: 17kg
Gross Weight:
19kg(Carton)
54kg(2 in 1
flightcase)
