The appearance design is exquisite, the housing adopts high-strength PA66, anti-UV treatment, high temperature resistance, anti-aging, IP55 dynamic rotating computer moving head beam light, using 380W gas discharge lamp as the light source, color temperature 8000K, beam angle 1.9-3°, linear zoom, High-efficiency output waterproof moving head beam light with long service life. A color wheel, a fixed gobos wheel, 2 independent rotating prisms, two-way rotation can be rotated forwards and backwards to to adjust the frost effect,Pan/Tilt adopts three-phase motors, high-speed, smooth, stable and precise mechanical movement, in addition to DMX control, there is also a powerful RDM control technology.
● Optics
. Light source:Osram 380W lamp
. Beam angle : beam mode: 1.9°~3°
. Lens diameter： 150mm
● Scanning
. Pan / tilt operation：
※16bit fine-tuning
※Smooth and precise positioning
※Pan : 540 °,Tilt 270 °
※Pan/Tilt speed can be ajustable
※The scanning position can be memorized, and it will be reset automatically after no expected operation.
※Pan and tilt with error correction function
● Colour
. Color wheel: 13 static colors + Open, the color wheel has half-color effect and continuous forward and reverse of the rainbow effect
Gobos
. 1 static gobos wheel:17gobos+White circle, pattern jitter effect
● Specification
. 3DMX channel modes: 19/23/27CH international standard DMX512 channels
. 2 control modes: DMX512, master-slave
. 2 two-way prsim wheels: prism wheel with prism overlap and positioning macro function
. Focus: electronic focusing, ultra-smooth adjustment
. Dimming:0-100% linear dimming
. Frost:0-100% linear frost
. Strobe effect : Strobe0-20Hz、Puls Strobe、Random strobe
● Display
. 2.4-inch TFT color display
. High anti-interference four-button touch button
. The display board can be reversed by 180 °, which is suitable for installation in unreasonable positions.
● Software
. oftware update :Update fast and conviniently via DMX link
. Display the light usage time, which is convenient for customers to know the light usage in time
● Other functions
. Setting and addressing：RDM
. Heat cooling design: adopts wind direction drainage and temperature intelligent monitoring technology, which can monitor the status of lamp start, use, close shutter, and close bulb lamp. According to the temperature of different positions of the lamp, the heat cooling system is automatically adjusted to effectively control the temperature of the lamp. The internal multi-point intelligent temperature sensor is simultaneously displayed on the display screen. (Customizable humidity and temperature synchronization display control function)
● Power / DMX connection
. Power connection:3pin waterproof power cable input and output
. DMX XLR socket：3 Pin waterproof XLR socket input, output
● Power
. AC100-240V 50/60HZ
. Power consumption：470W
● Protective class
. Housing material: PA66, high temperature resistance, extreme cold resistance, corrosion resistance, aging resistance, UV resistance
. Waterproof level: IP55
● Working environment
. Indoor working temperature：-20°C～+40°C
● Size and weight
. Packing size：390x320x670mm
. Net weight：25KG
. Gross weight：27.5KG
● Certification：
. CE,ROHS
